OHAUS a-AB41PH-F Bench PH Meter (-2.00~20.00 pH)

pH

Measuring Range: -2.000 to 20.000 pH

Resolution: 0.1/0.01/0.001 pH

Selectable Resolution: Yes

Accuracy: ± 0.002 pH

Pre-Defined Buffer Groups: 5

ORP, RmV

Measuring Range: ± 2000.0mV

Resolution: 0.1 mV

Accuracy: ±0.3 mV

Units: mV, RmV

Temperature

Measuring Range: -10.0 to 125.0 °C ; 14°F to 257°F

Resolution: 0.1 °C, 0.1 °F

Accuracy: ± 0.3 °C, ±0.3 °F

Calibration: 1 point cal offset

Calibration

Calibration Points: Up to 5 points

Calibration Sign: Slope/offset & Face

Calibration Mode: Linear

Meter Specifications

Display Type 6.5" Segment & Dot matrix LCD with backlight

Multilanguage User Interface English, Spanish, French, Portuguese, Chinese, Russian and Turkish

Measurement End-point Modes Auto-stop, Timed, Continuous

Datalog for measurement 1000 sets data points with time and date stamp

Datalog for calibration 10 sets

Keypad Capacitive touch

Output Connect to PC via RS232 and USB, Connect to Printer via RS232

Password management 10 User ID  for password management

pH electrode input BNC

Temperature input Cinch, NTC 30 kΩ

Installation Overvoltage Category II

Pollution Degree 2

Power Supply Universal, 100-240 VAC, 50-60 Hz

Ambient Operating 5 to 40 ˚C, 5 to 80 %, non-condensing

Datasheet
