Core: HCS12X
I/O Voltage: 3.13 V to 5.5 V
Unit Weight: 829 mg
Data RAM Size: 64 kB
Data RAM Type: SRAM
Data ROM Size: 4 kB
Data ROM Type: EEPROM
Qualification: AEC-Q100
ADC Resolution: 2 x 8 bit/10 bit/12 bit
DAC Resolution: 16 bit
Data Bus Width: 16 bit
Interface Type: CAN, I2C, SCI, SPI
Mounting Style: SMD/SMT
Number of I/Os: 152 I/O
Watchdog Timers: Watchdog Timer
Processor Series: S12XE
Moisture Sensitive: Yes
Program Memory Size: 1 MB
Program Memory Type: Flash
Supply Voltage - Max: 1.98 V
Supply Voltage - Min: 1.72 V
Analog Supply Voltage: 3.13 V to 5.5 V
Number of ADC Channels: 16 Channel
Maximum Clock Frequency: 50 MHz
Operating Supply Voltage: 1.72 V to 1.98 V
Number of Timers/Counters: 25 Timer
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
