Core: HCS12X
Width: 20 mm
Height: 1.4 mm
Length: 20 mm
I/O Voltage: 3.15 V to 5.5 V
Unit Weight: 1.278 g
Data RAM Size: 8 kB
Data RAM Type: RAM
Data ROM Size: 2 kB
Data ROM Type: EEPROM
Qualification: AEC-Q100
ADC Resolution: 10 bit
Data Bus Width: 16 bit
Interface Type: CAN, SCI, SPI
Mounting Style: SMD/SMT
Number of I/Os: 59 I/O
Watchdog Timers: Watchdog Timer
Processor Series: S12XD
Moisture Sensitive: Yes
Program Memory Size: 128 kB
Program Memory Type: Flash
Supply Voltage - Max: 2.75 V
Supply Voltage - Min: 2.35 V
Analog Supply Voltage: 3.15 V to 5.5 V
Number of ADC Channels: 24 Channel
Maximum Clock Frequency: 80 MHz
Operating Supply Voltage: 2.35 V to 2.75 V
Number of Timers/Counters: 4 Timer
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
