Rated capacity (R.C.): ±500.0N (±50.00kg)
Available display range: ±500.0N (±50.00kg)
Display resolution: 0.1N/0.01kg
Unit: Unit change between N and kg (g) (reverse display available)
Measurement method: Normal measurement, plus peak, minus peak
Display cycle: 1 time/sec, 2 times/sec, 3 times/sec, 5 times/sec, 10 times/sec, 20 times/sec
Sampling cycle: 1000 times/sec
Accuracy: ±0.2%R.C. and ±1/2digit (at 23°C) N
Display: LCD Signed 4-digit display (Font height: 12mm) Judgment LEDs (HI_NG, OK, Lo_NG) 3 pieces
Overload capacity: 150%R.C.
Comparator function: Judges Hi_NG, OK, and Lo_NG, and outputs using the judgment LEDs and output signals
Communications: [USB] (PCs can communicate with the unit using the specialized communication software.(USB cable optional)
[RS-232C] (PCs can commu unit using the specialized communication commands (RS-232 cable optional )
Analog: ±1V (Outputs for the available range of display), accuracy ±50mV, 12bitD/A converter method Output updates: 1000 times/sec, zero setting available, load resistance 10kΩ or more
Output: [Overload] PUSH, PULL Open collector output (max. DC30V/5mA) (Comparator] HI, OK, LO Open collector output (max. DC30V/5mA)
Input signal: ZERO (external zero setting), HOLD (external hold), PEAK (peak mode setting)
Power: built-in NiMH battery (rechargeable)
Battery operating time: Approx. 10 hours from full charge
Charging time: Max. 17 hours (Automatically ends when fully charged)
Auto power off function: 10 min (The unit can be used while connected to the AC adapter), this function can be disabled.
Memory function: Continuous memory 1000 sets/Single memory 100 sets/Standard memory 50 sets (can be switched between the three memory modes) Equipped with statistics function (max., min., peak, average, standard deviation)
Operating temperature (humidity) range: Temperature]0 to 40°C (No condensation) [Humidity 35 to 85%RH (No condensation)
Accessories: Measurement adapters (6 types)
