NIDEC-SHIMPO FGP-50 Digital Force Gauge (±500.0N (±50.00kg))

Rated capacity (R.C.): ±500.0N (±50.00kg)

Available display range: ±500.0N (±50.00kg)

Display resolution: 0.1N/0.01kg

Unit: Unit change between N and kg (g) (reverse display available)

Measurement method: Normal measurement, plus peak measurement, minus peak measurement

Display cycle: 1 time/sec, 2 times/sec, 3 times/sec, 5 times/sec, 10 times/sec, 20 times/sec

Sampling cycle: 1000 times/sec

Accuracy: ±0.2%R.C. and ±1/2digit (at 23ºC)

Overload capacity: 200%R.C.

Tracking function: Provided (can be switched ON/OFF)

Auto power off function: 10 min (The unit can be used while connected to the AC adapter), this function can be disabled.

Memory function: Continuous memory 1000 sets/Single memory 100 sets/Standard memory 50 sets (can be switched between the three memory modes) Equipped with statistics function (max,, min., peak, average, standard deviation)

Comparator function: Available (upper and lower limits)

Operating temperature (humidity) range: [Temperature 0 to 40°C (No condensation) [Humidity 35 to 85%RH (No condensation)

External dimensions: Width 75 x Thickness 38 x Length 147mm

Weight: Approx. 450kg

Accessories: Measurement adapters (6 types), hanger, AC adapter, carrying case, USB cable
