Voltage: 120V/CH
Current: 20A/CH
Power: 150W/CH
Min operating voltage: 1V@20A
Channel: 12CH
CC mode
Range: 0~20A
Setting Resolution: 1mA
Setting Accuracy (23±5℃): 0.05%+0.1%F.S
CV mode
Range: 0~120V
Setting Resolution: 10mV
Setting Accuracy: (23±5℃) 0.05%+0.05%F.S.
CP mode
Range: 0~150W
Setting Accuracy (23±5℃): 0.15%+0.15%F.S
CR mode
Range: 50mΩ~1kΩ
Setting Accuracy (23±5℃): 0.15%+10μS
Current Measurement
Range: 0~20A
Readback Resolution: 1mA
Readback Accuracy (23±5℃):0.05%+0.1%F.S.
Voltage Measurement
Range: 0~120V
Readback Resolution: 10mV
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
Interface: LAN/RS485
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Sampling Frequency: 25Hz
Communication Response Time: ≤10ms
Operating Environment: Altitude: <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Net weight: Approx. 21kg
Dimension: 3U, 132.5(H)*482.0(W)with handle*495.0(D)mm
