Voltage: 150V/CH
Current: 4A/CH
Power: 200W/CH
Channels: 4CH
CV Mode
Range: 0~150V
Setting Resolution: 10mV
Setting Accuracy ( 23±5℃): 0.05%+0.1%F.S
Setting Temperature Coefficient ( 0-40℃): 50ppm /℃
Readback Resolution: 10mV
Readback Accuracy (23±5℃): 0.05%+0.1%F.S.
CC Mode
Range: 0~4A
Setting Resolution: 1mA
Setting Accuracy ( 23±5℃): 0.1%+0.1%F.S
Setting Temperature Coefficient (0-40℃): 50ppm /℃
Readback Resolution: 1mA
Readback Accuracy (23±5℃): 0.1%+0.1%F.S.
Readback Temperature Coefficient: 50ppm/℃
Voltage Ripple(20Hz-20MHz): 300mVp-p, 25mVrms
Load Regulation: ≤0.03%(Voltage) / ≤0.05%(Current)
Line Regulation: ≤0.015%(Voltage) / ≤0.05%(Current)
Interface: RS232/LAN
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Temperature: Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 10kg
Dimension: 2U, 88.0(H)*482.0(W)*560.0(D)mm
