Image Sensor: 1280×800 (MP) CMOS
Light Source: White LED & Red LED (622nm-628nm)
Barcodes: 1D; 2D
Resolution: ≥3mil
Depth of Field: EAN-13: 50mm-495mm (13mil). Code 39: 85mm-220mm (5mil). PDF 417: 70mm-215mm (6.7mil). Data Matrix: 50mm-220mm (10mil). QR Code: 20mm-325mm (15mil).
Scan Angle: Pitch: ±55°, Roll: 360°, Skew: ±55°
Field of View: Horizontal 39°, Vertical 24°
Minimum Symbol Contrast: 25%
Aiming Light: Blue LED (515nm-535nm)
Communication Modes: Synchronous, Asynchronous, and Batch Modes
Radio Technology: Bluetooth 5.0
Communication Distance: 50m/164ft (outdoor line of sight)
Battery: 2400 mAh lithium-ion battery
Expected Charge Time: 4 hours (with power adapter)
Expected Battery Life: 12 hours continuous operation (scanning once every 6 seconds)
Memory Capacity: ≥15000 Code 128 segments (20 bytes per Code 128)
Connectivity: RS-232, USB
Operating Voltage: 5VDC±5%
Dimensions: Scanner: 113.5(W)×73.3(D)×159.0(H)mm
Weight: Scanner: 217g
Notification: Beeper; LED
Operating Temperature: -20°C to 60°C
Storage Temperature: -40°C to 70°C
Humidity: 5%~95% (non-condensing)
ESD: ±8 KV (air discharge); ±4 KV (contact discharge)
Drop Resistance: Scanner: 1.5m/4.9ft Cradle: 1m/3.3ft
Protection Standard: IP42
