Image Sensor: 1280×800 (megapixel) CMOS
Illumination: Red LED/ White LED
Symbologies: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey, etc.
PDF417, QR Code, Data Matrix, Aztec, Maxicode, etc.
USPS Postnet, Royal Mail, KIX Post, Australian Postal, etc.
Resolution: ≥3mil
Typical Depth of Field
55mm-570mm (13mil)
115mm-170mm (5mil)
85mm-225mm (6.7mil)
65mm-305mm (10mil)
25mm-395mm (15mil)
Scan Angle: Pitch: ±55°, Skew: ±55°, Roll: 360°
Min. Symbol Contrast: 25%
Field of View: Horizontal 39°, Vertical 24°
Aiming: Green LED
Physical
Dimensions (L×W×H): 113.5(W)×73.3(D)×159.0(H)mm
Weight: 162g
Notification: Beep, LED
Operating Voltage: 5VDC±5%
Current@5VDC: 238.2mA (typical), 260.5mA (max.)
71.3mA
Interfaces: RS-232, USB
Rated Power Consumption: 1289.6mW (typical)
Environmental
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5%~95% (non-condensing)
ESD: ±15 KV (air discharge); ±8 KV (contact discharge)
Drop: 1.5m
Sealing: IP42
Certifications
Certificates & Protection FCC: Part15 Class B, CE EMC Class B, RoHS
