Image Sensor: 1280 × 960 CMOS
Illumination: Direct: White and red LED; Diffused: Blue LED ring; LED 532 nm
Barcode Types:
• 2D: QR Code, PDF417, Micro QR, Data Matrix, AZTEC
• 1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code128, Code93, Code11, COOP25, GS1-128 (UCC/EAN-128), ITF-6, ITF-14, AIM128, ISBT128, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, MSI Plessey, Code 39, Plessey, Deutsche 14, Deutsche 12
Resolution: ≥ 3 mil
Depth of Field:
• EAN-13 (13 mil): 25 mm – 160 mm
• Code 39 (5 mil): 40 mm – 100 mm
• Code 39 (20 mil): 35 mm – 210 mm
• Data Matrix (10 mil): 0 mm – 125 mm
• QR Code (20 mil): 20 mm – 180 mm
Scan Angle: Pitch: ±50°; Roll: 360°; Skew: ±50°
Field of View: Horizontal 41°, Vertical 31°
Motion Tolerance: 2 m/s
Minimum Print Contrast: 20%
Interface: USB, RS232, PS/2
Operating Voltage: 5VDC ±5%
Rated Power Consumption: 1600 mW (typical)
Current @ 5VDC: Operating (typical): 320 mA; Maximum: 480 mA
Dimensions (W × D × H): 67 × 86 × 170 mm
Weight: 165 g
Indication: Beep, LED, Vibration
Operating Temperature: -20°C to 50°C
Storage Temperature: -40°C to 70°C
Humidity: 5%–95% (non-condensing)
ESD Protection: ±16 kV (air discharge); ±8 kV (direct discharge)
Drop Resistance: 1.8 m
Protection Rating: IP64
Certifications: FCC; CE; ROHS; IEC62471; BIS; KC
