Image Sensor: 2500 CCD
Illumination: Red LED 615 nm
Decoding Capability:
1D: Codabar, Code 128, EAN-13 Addendum, Code 39, Code 93, GS1-128 (UCC/EAN 128), EAN-8, EAN-13, UPC-A, UPC-E, Interleaved 2/5
Resolution: ≥6 mil
Depth of Field: 25–105 mm
Minimum Print Contrast: 25%
Beam Exit: Scan window with front beam exit
Scan Rate: 780 scans/second
Scan Angle: 68°
Dimensions: 62.5 (W) × 50.5 (D) × 21.5 (H) mm (maximum)
Weight: 120 g
Indicator: LED indicator
Rated Power Consumption: <3 W
Operating Voltage: 5–24 VDC ±5%
Current Consumption: @5VDC: 303 mA RMS (typical); @24VDC: 76 mA RMS (typical)
Interface: RS-232
Housing: Plastic
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5%–95% (non-condensing)
Ambient Light Resistance: 5000 lux
Protection Rating: IP54
