Range: 300°C to 1200°C
Resolution: 1°C
Accuracy: Better than ±3°C
Stability: Better than ±0.5°C (below 600°C)
Stabilisation Time: 20 Minutes (above 500°C)
Temperature Readout: °C / °F Switcheable
Well Diameter: 45 mm
Immersion Depth: 150 mm
Dry Block Material: Inconel
Heating Time (to max.): 90 Minutes
Cooling Time (without well air cooling): 45 Minutes approx.
Multihole Thermowell: 4 x 7 mm + 3 x 9 mm or to suit
Switch Test facility/ Supply: Provided / 5 VDC (open)
Power Supply / Consumption: 230V AC / 50 Hz / 1850 W
Temperature Control: Auto-tune PID Control
Forced Air Cooling ** : Provision available
Transmitter Power Supply: 24V DC
Instrument Dimensions (L x D x H): 205 x 365 x 480 mm
Instrument Weight (approx.): 16 Kg
-Standard Delivery:
Basic Instrument
Cable for Thermostat Switch Test
Mains Cable
Insertion Tube - Multihole
Tool for Insertion Tube
Spare Fuses
1/4” BSP (F) Hose Adaptor with 6 mm Hose (1.5 Meter
Length)
RS-232 Computer Interface
Traceable Calibration Certificate
Instruction Manual
-Optionals:
“Caltemp” Calibration Software
Calibration Certificate from NABL Accredited – as per ISO/IEC 17025:2005 Laboratory
115V AC / 60 Hz Model
