Dimension (WxDxH): 560㎜ x 760㎜ x 330㎜
Power: AC 220V, Single phase, 50~60Hz, 900W
Moter: 1kW BLDC Motor
Wheel Size: 4 ~ 7" (Arbor 12.7mm)
RPM: 300 ~ 5,000 RPM, Digital type
Cut Capacity: 30Φ(5" Wheel), Max. 40Φ
Safety: Cover open sensing, Cut Finish Alarm and Auto Stop
Advantage:
5.6” TFT LCD Touch Screen for easy use
Auto sensing wheel load during the cutting
User can input Absolute or Relative position for stage move
Display current position of stage
Control Cutting length in 1㎛ unit
Wheel RPM auto calibration
Stage Zero set available
Continuous Cutting through Schedule mode
Stage move FWD/BWD by Joystick
Save/Load Set value(Max. 5)
Increase cutting length precision by input Wheel thickness
Minimize Burr by add Rotation function(Option)
Controls: Power, Start, Stop, Speed Control, Pump
Coolant: Double layer filtered Pump (3 liter)
Precision: 0.001mm step
