P/N :AAA10F
Output voltage range 0.8 V - 13.5 V
Continuous current 6.0 A
Integrator cutoff frequency 300 kHz
Sample Rate 5KHz
Fine current scale - range 60 mA
Fine current scale – resolution 1 uA
Fine current scale - accuracy +/- 1% or +/- 50 uA (whichever is greater)
Coarse current scale - range 60 mA - 6.0A
Coarse current scale - resolution 100 uA
Coarse current scale - accuracy +/- 1% or +/- 1 mA (whichever is greater)
Programmable current limit range 8 mA - 15.625 A
Programmable current limit accuracy (0.7) * (current limit) (1.4) * (current limit)
PTC trip limit at 16 V DCIN Not applicable 14 A
Fan turn on temperature 1C 40C
Fan turn off temperature Fan turn on setpoint -
Thermal limit shutdown 75 C
