Color: Black
Pitch: 8.26 mm
Width: 12.7 mm
Height: 12.7 mm
Length: 34.9 mm
Unit Weight: 9.071 g
Current Rating: 15 A
Mounting Angle: Horizontal
Mounting Style: Through Hole
Number of Rows: 1 Row
Voltage Rating: 300 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 22 AWG
Contact Plating: Tin
Contact Material: Brass
Housing Material: Polybutylene Terephthalate (PBT)
Wire Orientation: Horizontal
Termination Style: Solder Pin
Number of Positions: 4 Position
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
