Measuring accuracy (at 20 degree C, when not loaded) : (2.2+0.02L) um - L : measuring length (mm)
Minimum reading : 1/05/01 um switchable
Incline angle : 0-30 degree (angle of column)
Observation image : erect image
Eyepiece : 10X is provied as standard, 15X, 20X are optional
Stage : 200x170mm
Max table loading : 20kg
Swiveling angle : +/- 5 degree
Internal light source :
+ LED Illumintation : White LED (transmitted/vertical refected), no step modulated light
+ Hallogen :
12V, 50W (transmitted)
12V, 100W (vertical reflected)
15V, 150W (vertical reflected) - optional.
Dimension (wxdxh)
+ Main unit : 642x892x782
+ Controll unit for illumination unit : 114x360x96
Output : RS-232C, USB output for Vision unit
Mass : 150kg
AC power input connector : 100-240V
