Bandwidth: 0.1MHz~20MHz
Gain: 120dB, Pace 0.1dB,0.6dB,1dB,2dB,6dB
Wave Filter: Broadband,1m,1.25m,2.5m,5m,10m,15m,1m-5m
Sampling Rate: Hardware Sampling Rate 100MSPS,Equivalent Sampling Rate 400MSPS
Detection Mode: Full Wave, Positive Half Wave, Negative Half Wave, RF, Envelope
Detection Range: 20 Meters (Longitudinal Wave Carbon Steel),Pace 100mm, 10mm, 0.1mm
Sound Velocity: 250~16000m/s
Pulse Mode: Sharp Pulse, Square Wave, Dual-square Wave
Pulse Voltage: 25V~300V , 25V Pace
Pulse Width: 0ns~500ns Continuously Adjustable, 5ns Pace
Emission Damping: Strong, Weak Adjustable
Pulse Frequency: Automatic Or Manual, Automatic Range(200Hz-1KHz),Manual Range(0-10KHz)
Probe Channel: 200 Groups, Supporting Operations Such As Creating, Previewing, Deleting, Renaming, Overwriting, And Restoring
Gate Alarm: Gate A And B Alarm, Lost Wave/Incoming Wave
Gate Mode: Independent Gate A, Gate B
Measurement Mode: Peak, Front Edge, J Front Edge
Quantitative Mode: DAC Curve ,AVG(DGS) Curve
Flaw Detection Standards: AWS D1.1/D1.5,NB/T 47013,GB/T 29712,GB/T 11345
Saving Content: Single Frame, Multi-frame Recording (≤ 500 Frames), Screenshot,Flaw Detection Report
Auxiliary Functions: Automatic Gain, Peak Memory, Waveform Freezing, Channel Management, Gate Alarm, Gate Expansion, Automatic Gate, Full Screen Touch, Virtual Keyboard, Color Half Span, Quick Screenshot, Channel Import/Export
Display Screen: 5.0 Inch 800×480 IPS_LCD
Probe Interface: Dual LEMO-00 C5
Output Interface: Type-C1,Mini USB
Charger: 30W_PD Fast Charging ,Standard Type-C Interface(100~240V,50~60Hz)
Size: 183mm×113mm×45mm
Weight: 700g,Including Battery But Not Rubber Sleeve
Language: English, Russian or Other Customized Languages
Unit: Metric System ,Imperial System
Battery: 7.4V 8000mAh aLithium Battery, 12 Hours Of Battery Life
Resolution Ratio: 30dB(Metrological Performance Requirements: ≥26dB)
Dynamic Range: 35dB(Metrological Performance Requirements: ≥26dB)
Sensitivity Margin: 55dB(Metrological Performance Requirements: ≥42dB)
Vertical Linearity: 1.2%(Metrological Performance Requirements: ≤6%)
Horizontal Linearity: 0.15%(Metrological Performance Requirements: ≤2%)
Standard Delivery
Main Unit: 1 pc
Probe (High-precision Straight Probe, Angle Probe): 2 pcs
Probe Cord: 2 pcs
Charger: 1 pc
Power Cord: 1 pc
Sd Card(8g): 1 pc
Conversion Plug (USB To C): 1 pc
Optional Delivery
SD Card(16g, 32g, 64g): FD-SD16/32/64
Power Bank: FD-PB
