Rated input power: 850 W
Output power: 490 W
Maximum torque: 36 / 14 Nm // 319 / 124 in-lbs
Drill-Ø masonry: 20 mm / 25/32 "
Drill-Ø concrete: 18 mm / 23/32 "
Drill-Ø steel: 13 / 8 mm // 1/2 / 5/16 "
Drill-Ø soft wood: 40 / 25 mm // 1 9/16 / 1 "
No-load speed: 1100 / 3100 rpm
Revolutions at rated load: 640 / 1800 rpm
Maximum impact rate: 58900 bpm
Gears: 2
Chuck capacity: 1.5 - 13 mm // 1/16 - 1/2 "
Collar diameter: 43 mm / 1 11/16 "
Drill spindle with hexagonal recess: 6.35 mm / 1/4 "
Drill spindle thread: 1/2 " - 20 UNF
Chuck clamping type: Geared chucks
Weight (without power cable): 2.6 kg / 5.7 lbs
Cable length: 4 m / 13 ft
Vibration
Drilling in metal: 4.2 m/s²
Uncertainty of measurement K: 1.5 m/s²
Impact drilling concrete: 17 m/s²
Uncertainty of measurement K: 1.5 m/s²
Noise emission
Sound pressure level: 103 dB(A)
Sound power level (LwA): 114 dB(A)
Uncertainty of measurement K: 3 dB(A)
Datasheet
Vario (V)-Electronics for working at customised speeds to suit various application materials
Thumbwheel for Speed Preselection
Robust die cast aluminium gear housing for optimum heat dissipation and long service life
Rotating carbon brush bridge for maximum performance even in anti-clockwise operation, e.g. for the removal of stubborn screws
Metabo Marathon-motor with dust protection for long service life
Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the tool stop unexpectedly
Forward and reverse rotation
Spindle with hexagonal recess for screwdriver bits for working without chuck
Cable-protecting ball joint for optimal freedom of motion when working
