Max. single blow energy (EPTA): 18.8 J
Maximum impact rate: 2360 bpm
Rated input power: 1500 W
Drill-Ø concrete with hammer drills: 52 mm / 2 1/16 "
No-load speed: 200 / 270 rpm
Revolutions at rated load: 200 / 270 rpm
Bit retainer: SDS-max
Collar diameter: 85 mm / 3 11/32 "
Weight (without power cable): 12.4 kg / 27.3 lbs
Cable length: 6 m / 236 7/32 "
Vibration
Hammer drilling concrete: 14.1 m/s²
Uncertainty of measurement K: 1.5 m/s²
Chiseling: 9.7 m/s²
Uncertainty of measurement K: 1.5 m/s²
Noise emission
Sound pressure level: 98 dB(A)
Sound power level (LwA): 110 dB(A)
Uncertainty of measurement K: 3 dB(A)
Delivery
Rubber-coated side handle
Plastic carry case
Lubricant for tool shank end
Duster
Accessories
DRILLING/CHISELLING
SDS-max drill/chisel bits, Drill bit assortments, Core bits, Router bits, Further accessories for (impact) drills, Further accessories for rotary and chipping hammers
Datasheet
Features
Maximum drilling progress and high breaking performance thanks to maintenance-free brushless motor and high-performance hammer action
Long service life thanks to brushless technology and robust aluminium die-cast housings of gear and motor
Combination hammer with 2 functions: hammer drilling and chiselling
Metabo VibraTech (MVT) with double dampening: Decoupled handle and impact-absorbing counter-oscillating weight actively reduce vibrations for healthy working also in continuous use.
Ergonomically shaped, slim gripping area with large speed control trigger for comfortable working
Easily accessible locking switch for chiselling in continuous mode
Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
Optional reduction of speed and impact energy for working in softer materials
Electronic soft start for precise spot-drilling
Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
Restart protection: prevents unintentional start-up after power supply interruption
Overload protection: protects the motor from overheating
Low-dust chiselling and drilling with external dust extraction ESA max (accessories)
