Rated input power: 1400 W
Output power: 800 W
Maximum cutting depth at 90°: 66 mm / 2 19/32 "
Maximum cutting depth at 45°: 47 mm / 1 13/16 "
Saw blade Ø x bore: 190 x 30 mm / 7 1/2 x 1.181 "
Swivel range from / to: 0 / + 45 °
No-load speed: 4200 rpm
Revolutions at rated load: 3200 rpm
Max. cutting speed: 42 m/s / 138 ft/s
Torque: 9 Nm / 80 in-lbs
Weight (without power cable): 5.5 kg / 12.1 lbs
Cable length: 4 m / 13 ft
Vibration
Sawing chipboards: 2.5 m/s²
Uncertainty of measurement K: 1.5 m/s²
Noise emission
Sound pressure level: 95 dB(A)
Sound power level (LwA): 106 dB(A)
Uncertainty of measurement K: 3 dB(A)
Delivery
Carbide circular saw blade (14 teeth)
Aluminium parallel guide
Hexagonal wrench
Accessories
SAWING
Circular saw blades, Other accessories for jigsaws, Other accessories for circular saws
OTHER ACCESSORIES
Case systems, Accessories for wall chasers, Accessories for vacuum cleaners, Occupational safety, Accessories for paint remover, Accessories for routers
Datasheet
Features
Metabo S-automatic torque limiting clutch: mechanical decoupling of the drive for safe working should the saw blade stop unexpectedly.
Sturdy guide plate made from die cast magnesium
Grip area with non-slip soft-grip surface
Clearly visible cutting indicator for precise sawing after initial cut
0° position re-adjustable for highest cutting precision
Lubrication system for long service life of the gear
Extraction possibility by means of connecting an all-purpose vacuum cleaner
Controllable chip ejection by means of rotating extraction nozzle
Auto-stop carbon brushes to protect the motor
Adjustment of machine without tools for using with the precision guide rail
