VIEWING HEADS
Binocular head with 45° inclined tube, fully rotatable over 360°
Dioptric adjustment for one eyepiece. Tube length 160 mm
Interpupillary distance between eyepieces can be controlled from 54 to 75mm
EYEPIECES
Reversed nosepiece for a maximum of 4 objectives. Ball-bearing mechanism and click-stops
OBJECTIVES
Achromatic DIN Semi-Plan 4x, 10x, S40x, 100x objectives. The S40x objectives is spring-mounted
NOSEPIECE
Revolving quadruple reversed nosepiece on ball-bearings.
STAGE
135 mm round metal stage with two stainless steel clamps. Vernier with Allen locking screw
POLARIZING EQUIPMENT
Analyzer is fitted in a slider and is located under the head. A swing-out polarizer fits on the light collector lens and is 360° graduations rotatable
FOCUSING ADJUSTMENT
Coaxial coarse- and fine adjustment knobs on both sides with 0.002 mm graduations. Friction of focus control can be adjusted. Built-in protection system prevents any damage to specimen and objective
ILLUMINATION
The MT-93 is equipped with a LED adjustable illuminator, for optimal colour rendering.
Variable intensity controls are ergonomically placed.
CARRY HANDLE
Ergonomic built in carrying handle makes it easy for storage and portability before or after lab sessions
