Viewing Head:
Trinocular head with two extra binocular head. Siedentopf 30° inclined tubes
Interpupillary distance is adjustable between 50 to 75 mm.
Diopter ±5 adjustment on the left tube.
Eyepieces: Extended wide field EWF plan 10x eyepieces with 22mm field of view.
Nosepiece: Revolving quintuple reversed nosepiece on ball bearings.
Objectives:
Plan IOS 4x/0.10, 10x/0.25, S40x/0.65, S100x/1.25 oil immersion infinity corrected objectives.
Optics are anti-fungus treated and anti-reflection coated for maximum light throughput.
Stage: 216 mm x 150 mm rackless stage equipped with integrated 79 x 52 mm mechanical stage.
Focusing: Coaxial coarse and fine adjustments with 200 graduations. Precision 1 μm, 0.2 mm per rotation. Total travel approximately 24 mm.
Rack-stop for protection of slides and objectives. Friction adjustment.
Condenser: Height adjustable Abbe N.A. 1.25 condenser with an opening for optional sliders.
Illumination: Diascopic intensity adjustable 3 W NeoLED™ Köhler illumination with Internal 100-240 V power supply (CE).
iCare Sensor: the illumination of the microscope automatically switches off when the microscopist steps away from his position, saving energy.
