Rated capacities: 2.5 kN/ 250 kgf/ 550 lbf
Displacement:
Crosshead travel: 507 mm (20”)
Maximum headroom: 526 mm (20.7”)
Displacement resolution: 0.001 mm/ 0.000025in
Positional accuracy: ±0.130/300 mm (±0.005/11.81”)
Speed:
Speed range:
0.1 to 1200 mm/min
0.004 to 47.2 in/min
Speed accuracy: ±2% of indicated speed or ±20 µ/min, whichever is greater
Speed resolution: 0.1 mm/min/ 0.004 in/min
Maximum no. of cycles per test: 9999
Dimensions
Height: 941 mm (37”)
Width: 290 mm (11.4”)
Depth: 414 mm (16.3”)
Vertical daylight: 588 mm (23.1”)
Throat depth: 70.5 mm (2.8”)
Weight: 24 kg (53 lbs)
Electrical supply
Voltage: 230V AC 50 Hz/ 110V AC 60 Hz
Maximum power requirements: 250 W
