Width: 120 mm (4.724 in)
Height: 93 mm (3.661 in)
Length: 170 mm (6.693 in)
Industry: Industrial
Approvals: UL62368-1, TUV EN62368-1, EAC TP TC 004
Compliance: UL62368-1; TUV EN62368-1; EAC TP TC 004
Efficiency: 93.5 %
Unit Weight: 2 kg
Output Power: 1.008 kW
Input Voltage: 90 VAC to 264 VAC, 127 VDC to 370 VDC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 42 A
Output Voltage-Channel 1: 24 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
