Width: 9.2 mm (0.362 in)
Height: 11.1 mm (0.437 in)
Length: 21.8 mm (0.858 in)
Industry: Industrial
Dimensions: 21.8 mm x 9.2 mm x 11.1 mm
Efficiency: 83 %
Unit Weight: 4.800 g
Output Power: 3 W
Input Voltage: 18 V to 75 V
Cooling Method: Convection
Mounting Style: Through Hole
Mechanical Style: Isolated
Isolation Voltage: 1.5 kV
Number of Outputs: 2 Output
Input Voltage - Max: 75 V
Input Voltage - Min: 18 V
Input Voltage, Nominal: 48 V
Output Current-Channel 1: 125 mA
Output Current-Channel 2: 125 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
