Width: 7.6 mm (Max)
Height: 2.35 mm (Max)
Length: 11.75 mm (Max)
Supply Type: Single Supply, Dual Supply
Configuration: 1 x 8:1
On Time - Max: 1.5 us
Mounting Style: SMD/SMT
Off Time - Max: 1.5 us
Number of Channels: 8 Channel
On Resistance - Max: 450 Ohms
Supply Current - Max: 2.5 mA
Supply Voltage - Max: 30 V
Supply Voltage - Min: 5 V
Pd - Power Dissipation: 762 mW
Operating Supply Voltage: 9 V, 12 V, 15 V, 18 V, 24 V, 28 V
Maximum Dual Supply Voltage: +/- 20 V
Minimum Dual Supply Voltage: +/- 4.5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
