Rated input voltage: AC220V/110V±10%
Rated output voltage: 0~20V
Rated output current: 0~10A
Rated output power: 200W
Load regulation rate: Voltage 0.05%+8mV, Current 0.1%+5mA
Line regulation: Voltage 0.05%+8mV, Current 0.1%+5mA
Setting value resolution: Voltage 1mV, Current 0.1mA
Readback value resolution: Voltage 1mV, Current 0.1mA
Setting accuracy (25°C±5°C): Voltage ≤0.1%+2 digits, Current ≤0.2%+3 digits
Readback accuracy (25°C±5°C): Voltage ≤0.1%+2 digits, Current ≤0.2%+3 digits
Ripple: Voltage 1.5mVrms, Current 3mArms
Temperature coefficient: Operation 300ppm, Storage 300ppm
Instrument size (WxHxD): 215x95x300 mm
Net weight: 6.7kg
Gross weight: 7.8kg
Datasheet
Manual
Catalog
Features
•List programme output function
• Save last time output data and state
• External trigger function
• Pass/fall signal output function
• Nine sets of voltage and current storage and recall function, convenient and quick
• Intelligent temperature control fan, extremely practical
• The knob adopts the code switch, which is convenient to use and has the function of preventing misadjustment
Applications
■Routine test and maintenance of production line;
■Laboratory and Research Institute;
■Simulation test of new energy vehicles;
■Automation equipment integration test
