Mahr PLM 1000-E Precision Length Measuring Machine (outer 0~1000mm, inner 0.5~845mm, , 0.085 + L/1500 µm)

Direct measuring range (mm): 200

Measuring range for outer measurement (mm): 0-1000

Measuring range for inner measurement (mm): 0.5-845

Measuring uncertainty MPEE1(L in mm) (µm): ≤ (0.085 + L/1500)

Repeatability (µm): ≤ 0.05

Measuring forces (N): 0-13.9

Device length (mm): 2110

Mass (kg): 535

ACCESSORIES

• Large number of accessory kits and modular

components for completing a wide variety of

measuring tasks, including the measurement of:

• Thread gages

• Conical thread gages

• Gears

• Thread pitches
