Test Force: 10gf (0.098N), 25gf (0.245N), 50gf (0.49N), 100gf (0.98N), 200gf (1.96N), 300gf (2.94N), 500gf(4.9N), 1kgf (9.8N)
Min. Measurement Unit: 0.031µm
Scale Conversion: HRA, HRB, HRC, HRD, HRF, HV, HK, HBW, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T
Hardness Range: 8 ~ 2900HV
Test Force Application Method: AUTO (Loading, Dwelling, Unloading)
Microscope Magnification: 100X (Observation) 400X (Measurement)
Test Force Dwelling Time: 0 ~ 60s
XY Test Bench: 100 * 100mm, Max. Moving Distance 25 * 25mm
Data Output: LCD Display, Built-in Printer and RS-232 Interface
Max. Height of Test Sample: 80mm
Distance from Indenter Center to Outer Wall: 95mm
Power Supply: AC220V+5%, 50-60Hz
Dimension: 405*290*480mm
Weight: 40Kg
