General
Memory: 21,504 readings
Reading Rate: 4 readings per second up to 1 reading every 24 hours
Baud Rate: 125000
Battery Life: 2 years typical (1 minute reading rate); User Replaceable Battery
Material: 316 Stainless Steel, Radel
Dimensions: 2.14 in x 0.97 in x 0.97 in (54.5 mm x 24.6 mm x 24.6 mm)
Key Ring End Cap: Key ring replaces standard bottom; Thru-hole: 0.150"
IP Rating: IP40 - logger alone (with no probe connected) ; The logger will inherit IP rating of the attached probe (up to, and including IP68/IP69K).
Submersible: Yes (with probe attached)
Operating Environment: -40 °C to +140 °C (-40 °F to +284 °F) 0 %RH to 100 %RH non-condensing, 0.002 PSIA to 60 PSIA (Body of Logger cannot Exceed 140 °C)
Required Interface Package: IFC400 or IFC406
Approvals: CE
Temperature:
Temperature Sensor: Various RTD Probes with M12 Connector (Sold Separately)
Temperature Resolution: 0.0001 Ω, (0.01 °C / 0.018 °F) (Probe Dependent)
Temperature Calibrated Accuracy:
±0.0462 Ω (18 Ω to 200 Ω)
±0.1 °C (-200 °C to +265 °C / -328 °F to +509 °F)
±0.1% of Reading (+265 °C to 850 °C / +509 °F to 1562 °F) (Probe Dependent)
Probe Temperature Range: 18 Ω to 400 Ω, -200 °C to +850 °C (-328 °F to +1562 °F) (Probe Dependent) (Body of Logger Cannot Exceed 140 °C)
