Description:
Digital hydraulic universal testing machine is mainly used for tensile, compression, bending and shearing tests of metal, non-metal, composite and products. It can also be tested and processed according to various standards provided by GB, ISO, JIS, ASTM, DIN. Widely used in aerospace, mechanical manufacturing, wire and cable, rubber and plastics, building materials and other industries, material inspection, and analysis are the scientific research institute, colleges and universities, industrial and mining enterprises, technical supervision, commodity inspection and arbitration and other departments of the ideal testing equipment.
Specification:
Max Test Force: 300 kn
Measure Range: 5-100 %
Relative Error Value: ±1/±0.5 %
Max Tensile Space: 480 mm
Max Compression Space: 480 mm
Piston Stroke: 150 mm
Size of Upper and Lower Platen: Φ176, Φ176 kw
Voltage: AC220/AC380V±10% 50Hz
Machine Size: 770*520*1850 mm
Net Weight: 1600 kg
