Scope of application:
1, determine the Brinell hardness of ferrous metals, non-ferrous metals and bearing alloy materials;
2, hard cast steel, aluminum alloy, copper alloy, malleable casting, mild steel, tempered steel, annealing steel, bearing steel, etc.
Main technical parameters
Measuring range: 5-650HBW
Test force: 306.25 (Optional), 612.9, 980.7, 1225.9, 1838.8, 2451.8, 4903.5, 7355.3, 9807, 14710.5, 29421N (31.25 (Optional), 62.5, 100, 125, 187.5, 250, 500, 750, 1000, 1500, 3000kgf)
Maximum allowable height of specimen: 260mm
Distance from indenter center to machine wall: 165mm
Cover charge time: 1-99s
Ratio of the objective: 1X,2X
Total magnification: 20X,40X
Resolution of hardness: 0.1HBW
Minimum unit of measurement: 0.625μm
The power supply: AC 220V,50Hz
Overall dimensions: 700*268*930mm
Camera resolution: 300 w pixel
CCD measurement method: Automatic and manual
weight: 160kg
