Capacity Choose: 10KG,20KG,50KG,100KG,200KG,500KG Optional
Accuracy Level: 0.5Level
Effective force measure: 0.4％～100％
Force accuracy: ±0.5％
Resolution Max load: 1/±250000
Load cell: Basic configuration: tension and pressure sensors
(maximum load)
Effective test widty: 150mm
Total Column height: 1000mm
Effective tensile stroke: 500mm
Test speed range: 0.1～500mm/min
Motor: Servo Motor
Displacement measure accuracy: ±0.5％
Safety device: Electron limit protection
Test table return function: Manual or automatic options, automatic or manual return to the initial position of the test after the end of the test
Over load protection: Over 10% of maximum load, automatic protection
Clamping fixture: Tensile fixture 1set
Machine size: 420×350×1350mm
Motor: 220V±10% 0.2KW/0.4KW
Weight: 70 Kg
