1. Combustion chamber: 300x, 1200 x depth and 450mm;
2. Combustion burner: 1KW combustion nozzle (based on GB/t5169.14-2007 / iec60695-11- 2:2003 standard), the blue flame height: 50 ~ 60mm, and the total height of the flame: 170 ~ 190mm.
3. Gas: the gas with a high purity of 95%
4. Sample installation:
5. Sample length: 600-plus / 25mm; The distance between the upper bracket of two horizontal supports and the upper margin of the lower bracket: 550mm;
5. For fire time: 0.1-999.9S continuous setting, the flame can be continuously burnt during the set time.
6. Installation position of the burner: the upper bracket of the blue flame contact point distance: 475mm, and the vertical axis of the spray lamp and the sample: 45 degree angle
7. Control function: manual or automatic;
8. Range of gas flow: 100-1000ml/min; Air flow range: 1-10l/min;
10. Pressure gauge: 0~0.75kpa range adjustment
11. Ignition mode: high voltage automatic ignition
