Application range
1. Ferrous metal, non-ferrous metal, IC sheet, surface coating, and laminated metal;
2. Glass, ceramics, agate, gemstones, thin plastics, etc.
3. Hardness test of depth and gradient of carbonized and quenched layers.
Technical parameters
Measuring range: 5-5000HV
Test force:
9.807N(1.0kgf) 49.03N(5.0kgf) 98.07N(10.0kgf) 196.1N(20kgf) 294.2N(30kgf) 490.3(50kgf)
Optical measuring system
Objective lens: 10×,40×
Total magnification: 100×,400×
Measuring range: 200μm
Division value: 0.025μm
Dimension: 620*330*640mm
Maximum allowable height of specimen; 200mm
Distance from head center to machine wall: 130mm
Power supply: AC220V/50Hz
Weight: 70Kg
