Wide voltage range design: (110-220V;50/60Hz), good compatibility
Adjustable variable speed: 5~95 c.p.m(stepless speed regulation)
Micro-computer control, LCD displays data.
Parameters set freely and permanently storage.
Wide voltage range design: (110-220V;50/60Hz), good compatibility
Adjustable variable speed: 5~95 c.p.m(stepless speed regulation)
Micro-computer control, LCD displays data.
Parameters set freely and permanently storage.
Control and resolve the problems of low bad abrasion resistance and easy falling-off of ink layer
of printing works.
By test, controls production technique efficiently, avoids loss of goods returns caused by bad quality.
The specimen’s coating and receptor rub each other under specified speed and pressure load. Determine the abrasion of coating or ink layer by testing the decrement of coating concentration or decrement of coating thickness.
Motor Power: 50W 110V~220V 50/60Hz
Rubbing Pressure: 10±0.1 N (abrasive head,1pc);10±0.1 N (additional weight,1pc)
Rubbing Speed: (5-95)times/min.(stepless speed regulation)
Rubber Pads Size: 25mm (L) x 50 mm (W)x 8mm (H)
Rubber Pads Hardness: 50Hs~53Hs
Rubber Medium: 80g/m2 clean coated paper, the width is 50mm
Rubbing Distance: 60mm (We also can offer special rubbing distance as 100mm,120mm and 155mm)
Settable Rubbing Times: 0~9,999
Suitable Specimen Size: 300 mm (L) x 60 mm (W)
Overall Dimension: 275mm×305mm×340mm (length by width by height)
Weight: 15KG
