Detection object: solid
Element detection range: Elements with atomic numbers ranging from 12 to 92 from magnesium to uranium
Analysis of the main elements in the alloy: Mg, Al, Si, S, P, Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, Zr, Nb, Mo, Ag, Cd, Sn, Sb, Ta, W, Pb, Bi 25 in total (can be added further)
Excitation source: 45KV/ 200Ua-Silver target terminal window integrated micro X-ray tube and high voltage source
Dimension: 245mm(L)X91mm(W)X319mm(H) weight ≤1.75KG (including battery)
Power supply: Rechargeable lithium battery, standard 6800mAh, voltage: 7.2V; Sustainable work up to 12 hours. The instrument has its own battery power display
Front-end test window: *≤9mm*5mm “waist” type window
Camera: With built-in 5 million pixel HD camera function, it can take photos of the object under test for easy management
Operating environment temperature and humidity: Humidity ≤90% -20ºC -+ 60ºC
Application fields and characteristics
Excellent performance (for field, non-destructive, fast, accurate)
High precision, fast speed, close to the laboratory level of analysis, can directly display the alloy brand and element percentage content and ppm content. The whole analysis process can be completed in just a few seconds, the alloy brand identification only takes 1~2 seconds, a one-click operation, even non-technical personnel can easily master.
Nondestructive testing (NDT)
It does not damage or affect the performance of the tested object and does not harm the internal organization of the tested object. There is no damage in the whole test process.
Analysis software
Remote control system, windows based PC terminal/Android based mobile phone terminal can operate the instrument through software, realize data synchronization across multiple platforms (instrument, PC terminal, mobile terminal, cloud), software has data analysis, spectrum display, report printing and other functions, instrument client has the function of sending analysis report by email; Remote control system, windows based PC terminal/Android based mobile phone terminal
can operate the instrument through software, realize data synchronization across multiple platforms (instrument, PC terminal, mobile terminal, cloud), software has data analysis, spectrum display, report printing and other functions, instrument client has the function of sending analysis report by email;
Recycling and sorting of waste
Recycling and reuse of scrap metal, multifusible alloy types and materials, on-site analysis, detection and sorting. To enable both buyers and sellers to make prompt and reliable decisions in the transaction. Quantitative analysis of ferrous alloy
(stainless steel, etc.), copper alloy, aluminum alloy, copper and iron alloy, lead-tin alloy, hybrid alloy and other metal components, as well as rapid material identification and sorting on site.
Application field and safety, standards (power plant, machinery, petrochemical etc.)
Alloy material identification (PMI) incoming inspection; Inventory material management; Installation material reinspection, prevent in petrochemical construction, metal smelting, pressure vessel, power station, petrochemical, fine chemical, pharmaceutical, casting, aerospace and other industries, mixing or use of unqualified materials will cause serious safety accidents, to ensure the process equipment material safety. Adapt to American Society for Materials and Testing (ASTM),
Chinese National standard (GB), UNS, power industry standard (DL), API, JIS, GMP, TSG, machinery industry standard (JB) and other industry and international and domestic standards.
Quality control and quality Assurance (QC/QA) and effective error prevention (PKKA-YOKE)
In the metal processing and manufacturing industry, quality control and quality assurance (QC/QA) of materials (raw materials), semi-finished products and finished products and effective anti-error (PKKA-YOKE) are essential. Mixing or using
unqualified materials will bring losses to enterprises. Everything from small metal mills to large aircraft manufacturers.
Data Processing and Enterprise Resource Planning (ERP)
WIFI, wireless Bluetooth and other ways of data transmission, files can be sent by E-mail, Bluetooth synchronous transmission, software synchronous transmission.
