Gender: Jack (Socket)
Polarity: Standard
Impedance: 50 Ohms
RF Series: N Type
Body Style: Bulkhead
Orientation: Straight
Body Material: Brass
Mating Cycles: 500 Cycles
Insertion Loss: - 0.18 dB, - 0.45 dB
Mounting Style: Through Hole
Voltage Rating: 1.5 kV
Contact Plating: Gold
Contact Material: Beryllium Copper
Maximum Frequency: 11 GHz
Termination Style: Solder Pin
Coupling Mechanism: Threaded
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
