Gain: - 0.45 dBi, - 1.27 dBi, - 1.37 dBi, - 1.78 dBi
VSWR: 2.0:1, 2.5:1
Style: Blade Tilt / Swivel
Length: 136.3 mm
Diameter: 20 mm
Bandwidth: 262 MHz, 460 MHz, 100 MHz, 200 MHz
Impedance: 50 Ohms
Application: Worldwide Cellular, Low Power Wide Area, ISM Applications, FirstNet Public Safety, IoT Devices, Gateways
Unit Weight: 16.535 g
Polarization: Linear
Power Rating: 5 W
Mounting Style: Panel Mount
Electrical Type: Dipole
Number of Bands: 4 Band
Center Frequency: 829 MHz, 1.94 GHz, 2.35 GHz, 2.6 GHz
Mechanical Style: Whip
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID, IoT, ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiMAX
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, CBRS, DCS, PCS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
