Gain: 5.1 dBi, 5.3 dBi, 4.9 dBi, 2.7 dBi
VSWR: 3.4, 3.1, 3.0, 5.0
Style: Multilayer
Width: 10 mm
Height: 2.8 mm
Length: 40 mm
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Worldwide Cellular, Low Power Wide Area, Smart Home Networking, Sensing, Remote Monitoring, IoT
Unit Weight: 3.117 g
Polarization: Linear
Power Rating: 10 W
Mounting Style: PCB Mount
Electrical Type: Embedded Monopole
Number of Bands: 4 Band
Center Frequency: 750.5 MHz, 875.5 MHz, 1.955 GHz, 2.352 GHz, 2.593 GHz
Mechanical Style: Chip
Ground Plane Size: 102 mm x 45 mm
Maximum Frequency: 2.69 GHz
Minimum Frequency: 698 MHz
Termination Style: SMD/SMT
Protocol - Sub GHz: RFID, IoT, ISM
Protocol - WiFi - 802.11: 802.11, LoRaWAN, SigFox, WLAN
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS, CBRS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
