Gain: 1.1 dBi, 1.3 dBi, 3.1 dBi, 3.3 dBi, 4.5 dBi, 5.1 dBi
VSWR: 1.3, 1.9, 2.2, 2.9, 3.2, 3.6
Style: Tilt/Swivel
Width: 28 mm
Length: 72.4 mm
Diameter: 10 mm
Impedance: 50 Ohms
Technology: Cellular
Wavelength: 1/4 Wave
Application: Worldwide Cellular, Low Power Wide Area, ISM Applications, FirstNet Public Safety, IoT Devices, Gateways
Unit Weight: 11.884 g
Polarization: Linear
Power Rating: 10 W
REACH - SVHC: Details
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 6 Band
Center Frequency: 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1500 MHz, 1800 MHz, 2400 MHz, 2700 MHz, 3300 MHz, 3800 MHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 3.8 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: SMA Plug
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 4G/5G, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
