Gain: - 1.6 dBi, - 1.8 dBi, - 1.9 dBi
VSWR: 2.0:1, 2.2:1, 2.4:1
Style: Multilayer
Width: 8.4 mm
Height: 1.1 mm
Length: 9.6 mm
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Single Band, Dual Band, ISM Applications, IoT Devices, Smart Home Networking, Sensing, Remote Monitoring, U-NII
Polarization: Linear
Power Rating: 5 W
Mounting Style: PCB Mount
Electrical Type: Embedded
Number of Bands: 3 Band
Center Frequency: 2.45 GHz, 5.4 GHz, 5.8 GHz
Mechanical Style: Chip
Ground Plane Size: 40 mm x 20 mm
Maximum Frequency: 5.875 GHz
Minimum Frequency: 2.4 GHz
Termination Style: SMD/SMT
Protocol - Sub GHz: IoT, ISM
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiMAX
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 5G, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
