Gain: - 0.6 dBi, - 1.5 dBi, - 2.2 dBi
VSWR: 2:1
Style: Tilt/Swivel
Length: 83.1 mm
Diameter: 9.4 mm
Impedance: 50 Ohms
Wavelength: 1/2 Wave
Application: Single Band, Dual Band, ISM Applications, IoT Devices, Smart Home Networking, Sensing, Remote Monitoring, U-NII
Unit Weight: 7.400 g
Polarization: Linear
Power Rating: 10 W
Mounting Style: Panel Mount
Electrical Type: Dipole
Number of Bands: 2 Band
Center Frequency: 2.4 GHz, 5.8 GHz
Mechanical Style: Whip
Maximum Frequency: 5.875 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: 802.11 b/g/n,/ac, WiFi 4, WiFi 5, U-NII
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
