Gain: 1.6 dBi
VSWR: 1.9
Style: Straight
Length: 83.5 mm
Diameter: 14.5 mm
Bandwidth: 200 MHz
Impedance: 50 Ohms
Cable Type: 216 mm RF1.32
Wavelength: 1/4 Wave
Application: FirstNet/Public Safety, Sensing, Remote Monitoring, Handheld Devices
Unit Weight: 22.236 g
Cable Length: 216 mm
Polarization: Linear
Mounting Style: Direct / Permanent Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 868 MHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 950 MHz
Minimum Frequency: 750 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID
Antenna Connector Type: MHF / U.FL
Protocol - WiFi - 802.11: LoRaWAN, Sigfox
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
