Gain: - 0.1 dBi, - 0.2 dBi
VSWR: 1.7, 2.1
Style: Stubby
Length: 83.1 mm
Diameter: 42 mm
IP Rating: IP67
Impedance: 50 Ohms
Wavelength: 1/2 Wave
Application: Low Power Wide Area Applications, Remote Control, Monitoring, Sensing, IoT, ISM
Polarization: Linear
Power Rating: 20 W
Mounting Style: Direct / Permanent Mount
Electrical Type: Dipole
Number of Bands: 2 Band
Center Frequency: 868 MHz, 915 MHz
Mechanical Style: Whip
Ground Plane Size: 300 mm x 300 mm
Maximum Frequency: 930 MHz
Minimum Frequency: 862 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID, IoT, ISM
Antenna Connector Type: N Female
Protocol - WiFi - 802.11: 802.11 ah, LoRaWAN, Sigfox, WiFi HaLow
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
