Work mode: infuse,withdraw,infuse /withdraw,withdraw/infuse,continuous mode
Number of channel: 1
Stroke of pump: 110mm
Advance per microstep: 0.156μm/μstep
Linear speed: 1μm/min ～150mm/min
Linear resolution: μm/min
Accuracy: error<±0.35%,(>30% of pump stroke)
Max rated linear force: >16kgf
Thrust regulation: 1～100% arbitrary adjustable
Syringe size: 10μL～60mL
Syringe selection: built-in main manufacturers, the main model syringe to choose.
Can use custom syringe, direct input syringe size and diameter
Flow rate: 0.184nL/min～83.318mL/min
Flow calibration: through the calibration procedure to obtain more accurate fluid volume
Display: 5-inch color LCD screen display and transfusion volume, residual fluid volume, flow ,operation direction, syringe specification, etc. Animation display operation
Operation mode: touch screen + button
Power-off memory: storing the running parameters automatically
State signal output: 1 road start-stop status ,1 road direction status
Control signal input: 1 road startup status ,1 road directional signal
Communication interface: RS485 communication interface, MODBUS protocol
Dimension mm(L×W×H): 240×196×125mm
Weight: 2.95kg
Power supply: AC100～240V，50/60Hz
Working environment: Temperature 5～40℃, relative humidity＜80%
