Basic Accuracy : R: 0.2%, L: 0.4%, C: 0.2%
Measurement Range (R) : 20mΩ to 10MΩ
Measurement Range (C) : 0.1pF to 5mF
Measurement Range (L) : 0.3uH to 1.0H
Test Frequency : 100Hz – 10kHz
Test Voltage : 0.5Vrms
Over Voltage Protection (between test tips) : Yes
Resistance (R) : Yes
Capacitance (C) : Yes
Inductance (L) : Yes
Impedance (Z) : No
Dissipation Factor (D) : Yes
Quality Factor (Q) : Yes
Phase Angle (Ө) : No
Equivalent Series Resistance (ESR) : Yes
Direct Current Resistance (DCR) : No
Diode Check : No
LED Testing : No
Continuity : No
Sorting : No
Recording : No
Self Calibration : Yes
PC Connectivity : No
Dimensions (L x W x H) : 151 x 19 x 14.5mm
Weight : 30g
Display : OLED 0.91″, 128 x 32 Resolution
Battery : 3.7V LiPO, 180mAH, Rechargeable
External Power Source : DC 5V, micro-B USB Connector
SMD Test Probe : Gold Plated (Regular)
