- Test load
0.098N (10gf), 0.246N (25gf), 0.49N (50gf), 0.98N (100gf),
1.96N (200gf), 2.94N (300gf), 4.90N (500gf), 9.80N (1000gf)
- Leus/indenter switch: Motorized Turret
- Carriage control: Automatic loading and unloading method
- Magnification of microscope
+ For measurement: 400X (Object lens 40x , eyepiece 10x)
+ For observation:200X (object lens 20x, eyepiece 10x)
- Load holding time: 5-60 second
- Measuring microscope: Min measuring unit: 0.0625um
- Testing field: 1-2967HV
- Micro test table: Dimensions 100x100mm
- Movement: 25mm in X&Y axis
- Max. height of specimen: 70mm
- Max. depth of specimen: 95mm
- Out put: Installed with innner-printer and RS232 interface
- Power supply: AC110V/220V 60/50HZ
- Dimensions: (L ) 425 X (W) 245X (H)490mm
- Weight: Gross Weight:: 42KG, Net Weight: 35KG
- Standard accessories:
Vickers Indenter, Objective (20X,40X), Digital Micro lens (10X),
XY-stage test table, Thin specimen test holder, Fork-shaped test holder,
Fine wire test holder, Adjustable screw, Lever, Micro Vickers hardness block, RS232 line
