Static Loading Range:
Heavyweight Platen and Ballast Kit
0.2 – 5.0 psi (0.014 – 0.35 kg/cm2)
Lightweight Platen and Ballast Kit (optional)
0.03 – 0.15 psi (0.0021 – 0.0105 kg/cm2)
Impact Velocity Range [Equivalent Drop Height]
Min. Impact Velocity 28 in./sec. (71 cm/sec.)
Min. Equivalent Drop Height 1 in. (2.5 cm)
Max. Impact Velocity 216 in./sec. (549 cm/sec.)
Max. Equivalent Drop Height 60 in. (152 cm)
PHYSICAL
Platen Sizes
Heavyweight Platen 9.06 x 9.06 in. (23 x 23 cm)
Lightweight Platen (optional) 8.5 x 8.5 in. (21.6 x 21.6 cm)
Platen Weights
Heavyweight Platen 12.8 lbs. (5.8 kg)
Lightweight Platen (optional) 1.92 lbs. (0.9 kg)
Machine Height 96 in. (244 cm)
Envelope Dimensions 18 x 18 in. (46 x 46 cm)
POWER REQUIREMENTS
Voltage 100 – 230 VAC
Frequency 50, 60 Hz.
Phase Single Phase
PNEUMATIC REQUIREMENTS
Plant Air 80 – 120 psi (5.6 - 8.4 kg/cm2)
