Gain: 3.5 dBi, 3.9 dBi, 4.8 dBi, 4.8 dBi, 4.4 dBi, 4.5 dBi, 4.4 dBi, 4.9 dBi, 5.4 dBi, 4.8 dBi
VSWR: 1.7:1, 1.7:1, 1.8:1, 1.4:1, 1.6:1, 1.6:1, 1.6:1, 1.7:1, 1.5:1, 1.8:1
Style: Panel
Width: 117.2 mm
Height: 7.6 mm
Length: 180.3 mm
Bandwidth: 3.5 GHz
Impedance: 50 Ohms
Cable Type: 30 cm Coax
Application: In-Building Systems
Unit Weight: 600 g
Cable Length: 30 cm
Polarization: Horizontal
Power Rating: 50 W
Mounting Style: Ceiling Mount
Number of Bands: 10 Band
Center Frequency: 752 MHz, 859 MHz, 920 MHz, 1450 MHz, 1785 Mhz, 1920 Mhz, 2040 MHz, 2400 MHz, 2600 MHz, 3550 MHz, 3900 MHz
Mechanical Style: Module
Maximum Frequency: 3.8 GHz
Minimum Frequency: 600 MHz
Termination Style: Connector
Protocol - Sub GHz: Radio, UHF, IoT, ISM
Antenna Connector Type: 4.3-10 Female
Protocol - WiFi - 802.11: WiFi, WiMAX
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), CBRS, WCS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
